Contact form: 1D (SPST-NC)
Contact material: Silver alloy
Contact load (resistive load) : 200A×48VDC（DC-1）
Contact pressure drop: ≤80mV@200A
Insulation resistance: Min. 100MΩ at 500VDC
Dielectric Strength: 1000VAC 50 HZ/60 HZ (1 minute) Leakage current less than 1mA
Pulse width: ( Only applicable to magnetic holding series )
Pull in time: Max. 40mSec.
Release time: Max. 40mSec.
Pull-in voltage (DC V): ≤70% US
Release voltage (DC V): ≥10% US
Operating ambient temperature: -25℃~+60℃
Storage temperature: -40℃~+65℃
Relative humidity: 20%~90% RH
Mechanical life: ≥150,000 times
Class of pollution: III
Working system: Continuous working system
Vibration:（10～200）Hz acceleration ≤3.5g
To attack:（60） Times / minute acceleration 6g
