It has a set of normally open contacts;
Coil power consumption is：22～29W Min～Max;
Scope of application：Power on off control of DC power supply systems such as oil pump startup, battery truck, electric forklift, electric winch, electric vehicle, excavator, automobile air conditioner, etc;
Features：Small size, high breaking capacity, sealing protection, and can adapt to harsh service environment;
Product certification: CE
Contact form: 1D (SPST-NO)
Contact material: Silver alloy
Contact load (resistive load): 200A
Contact pressure drop: ≤80mV@100A
Insulation resistance: Min. 100MΩ at 500VDC
Dielectric Strength: 1000VAC 50 HZ/60 HZ (1 minute) Leakage current less than 1mA
Instantaneous maximum current: 600A , ≤1S
Pull in time: Max. 30mSec.
Release time: Max. 50mSec.
Pull-in voltage (DC V): ≤70% US
Release voltage (DC V): 5～40% US
Operating ambient temperature: -25℃~+55℃
Mechanical life: ≥200000 Times
Degree of protection: IP67
Working system: Short term working system
Vibration: (10～200) Hz acceleration ≤3.5g
to attack:(60) Times / minute acceleration 6g
