Rated Voltage: 48VDC Max
Rated Current: 100/500 Amps/5 secs
Configuration: Normally Open (N/O)
Termination: M10X2 copper studs
Stud Torque: 15 ±1 Nm
Contacts: Copper
Hardware: Plated steel nuts and washers
Construction: Thermoplastic body with zinc
plated steel frame and plated brass bushing.
Operating Temp: -40°C to +85°C
